OpenStack에 OpenShift Container Platform 설치
초록
1장. OpenStack에 설치 준비
RHOSP(Red Hat OpenStack Platform)에 OpenShift Container Platform을 설치할 수 있습니다.
1.1. 사전 요구 사항
- OpenShift Container Platform 설치 및 업데이트 프로세스에 대한 세부 사항을 검토했습니다.
- 클러스터 설치 방법 선택 및 사용자를 위한 준비에 대한 문서를 읽습니다.
1.2. OpenStack에 OpenShift Container Platform을 설치할 방법 선택
설치 관리자 프로비저닝 또는 사용자 프로비저닝 인프라에 OpenShift Container Platform을 설치할 수 있습니다. 기본 설치 유형은 설치 프로그램이 클러스터의 기본 인프라를 프로비저닝하는 설치 관리자 프로비저닝 인프라를 사용합니다. 제공하는 인프라에 OpenShift Container Platform도 설치할 수 있습니다. 설치 프로그램에서 프로비저닝한 인프라를 사용하지 않는 경우 클러스터 리소스를 직접 관리하고 유지보수해야 합니다.
설치 관리자 프로비저닝 및 사용자 프로비저닝 설치 프로세스에 대한 자세한 내용은 설치 프로세스를 참조하십시오.
1.2.1. 설치 관리자 프로비저닝 인프라를 사용하여 클러스터 설치
다음 방법 중 하나를 사용하여 OpenShift Container Platform 설치 프로그램에서 프로비저닝하는 RHOSP(Red Hat OpenStack Platform) 인프라에 클러스터를 설치할 수 있습니다.
- 사용자 지정으로 OpenStack에 클러스터 설치: RHOSP에 사용자 지정 클러스터를 설치할 수 있습니다. 설치 프로그램을 통해 설치 단계에서 일부 사용자 지정을 적용할 수 있습니다. 다른 많은 사용자 정의 옵션은 설치 후 사용할 수 있습니다.
- 제한된 네트워크의 OpenStack에 클러스터 설치: 설치 릴리스 콘텐츠의 내부 미러를 생성하여 RHOSP에 OpenShift Container Platform을 제한되거나 연결이 끊긴 네트워크에 설치할 수 있습니다. 이 방법을 사용하여 소프트웨어 구성 요소를 받기 위해 활성 인터넷 연결이 필요하지 않은 클러스터를 설치할 수 있습니다. 이 설치 방법을 사용하여 클러스터가 외부 콘텐츠에 대해 조직의 제어 조건을 충족하는 컨테이너 이미지만 사용하도록 할 수 있습니다.
1.2.2. 사용자 프로비저닝 인프라를 사용하여 클러스터 설치
다음 방법 중 하나를 사용하여 프로비저닝하는 RHOSP 인프라에 클러스터를 설치할 수 있습니다.
- 자체 인프라의 OpenStack에 클러스터 설치: 사용자 프로비저닝 RHOSP 인프라에 OpenShift Container Platform을 설치할 수 있습니다. 이 설치 방법을 사용하면 클러스터를 기존 인프라 및 수정 사항과 통합할 수 있습니다. 사용자 프로비저닝 인프라에 설치하려면 Nova 서버, Neutron 포트, 보안 그룹과 같은 모든 RHOSP 리소스를 생성해야 합니다. 제공된 Ansible 플레이북을 사용하여 배포 프로세스를 지원할 수 있습니다.
1.3. 기존 HTTPS 인증서를 위해 RHOSP 엔드포인트 스캔
OpenShift Container Platform 4.10부터 HTTPS 인증서에는 SAN(주체 대체 이름) 필드가 포함되어야 합니다. 다음 스크립트를 실행하여 RHOSP(Red Hat OpenStack Platform) 카탈로그에서 CommonName 필드만 포함된 레거시 인증서의 각 HTTPS 엔드포인트를 스캔합니다.
OpenShift Container Platform은 설치 또는 업데이트 전에 기존 인증서의 기본 RHOSP 인프라를 확인하지 않습니다. 제공된 스크립트를 사용하여 이러한 인증서를 직접 확인합니다. 클러스터를 설치하거나 업데이트하기 전에 기존 인증서를 업데이트하지 않으면 클러스터 기능이 저하됩니다.
사전 요구 사항
스크립트를 실행하는 시스템에서 다음과 같은 소프트웨어가 있습니다.
- Bash 버전 4.0 이상
-
grep - OpenStack 클라이언트
-
jq - OpenSSL 버전 1.1.1l 이상
- 대상 클라우드의 RHOSP 자격 증명으로 머신을 채웁니다.
프로세스
다음 스크립트를 머신에 저장합니다.
#!/usr/bin/env bash set -Eeuo pipefail declare catalog san catalog="$(mktemp)" san="$(mktemp)" readonly catalog san declare invalid=0 openstack catalog list --format json --column Name --column Endpoints \ | jq -r '.[] | .Name as $name | .Endpoints[] | select(.interface=="public") | [$name, .interface, .url] | join(" ")' \ | sort \ > "$catalog" while read -r name interface url; do # Ignore HTTP if [[ ${url#"http://"} != "$url" ]]; then continue fi # Remove the schema from the URL noschema=${url#"https://"} # If the schema was not HTTPS, error if [[ "$noschema" == "$url" ]]; then echo "ERROR (unknown schema): $name $interface $url" exit 2 fi # Remove the path and only keep host and port noschema="${noschema%%/*}" host="${noschema%%:*}" port="${noschema##*:}" # Add the port if was implicit if [[ "$port" == "$host" ]]; then port='443' fi # Get the SAN fields openssl s_client -showcerts -servername "$host" -connect "$host:$port" </dev/null 2>/dev/null \ | openssl x509 -noout -ext subjectAltName \ > "$san" # openssl returns the empty string if no SAN is found. # If a SAN is found, openssl is expected to return something like: # # X509v3 Subject Alternative Name: # DNS:standalone, DNS:osp1, IP Address:192.168.2.1, IP Address:10.254.1.2 if [[ "$(grep -c "Subject Alternative Name" "$san" || true)" -gt 0 ]]; then echo "PASS: $name $interface $url" else invalid=$((invalid+1)) echo "INVALID: $name $interface $url" fi done < "$catalog" # clean up temporary files rm "$catalog" "$san" if [[ $invalid -gt 0 ]]; then echo "${invalid} legacy certificates were detected. Update your certificates to include a SAN field." exit 1 else echo "All HTTPS certificates for this cloud are valid." fi- 스크립트를 실행합니다.
-
스크립트가
INVALID로 보고하는 인증서를 SAN 필드가 포함된 인증서로 바꿉니다.
OpenShift Container Platform 4.10을 설치하기 전에 기존 HTTPS 인증서를 모두 교체하거나 클러스터를 해당 버전으로 업데이트해야 합니다. 다음 메시지와 함께 기존 인증서가 거부됩니다.
x509: certificate relies on legacy Common Name field, use SANs instead1.3.1. 기존 HTTPS 인증서를 수동으로 위해 RHOSP 끝점 스캔
OpenShift Container Platform 4.10부터 HTTPS 인증서에는 SAN(주체 대체 이름) 필드가 포함되어야 합니다. "기존 HTTPS 인증서로 RHOSP 끝점 스캔"에 나열된 사전 요구 사항 툴에 액세스할 수 없는 경우 다음 단계를 수행하여 공통Name 필드만 포함하는 레거시 인증서의 RHOSP(Red Hat OpenStack Platform) 카탈로그의 각 HTTPS 끝점을 스캔합니다.
OpenShift Container Platform은 설치 또는 업데이트 전에 기존 인증서의 기본 RHOSP 인프라를 확인하지 않습니다. 이러한 인증서를 직접 확인하려면 다음 단계를 수행합니다. 클러스터를 설치하거나 업데이트하기 전에 기존 인증서를 업데이트하지 않으면 클러스터 기능이 저하됩니다.
프로세스
명령줄에서 다음 명령을 실행하여 RHOSP 공용 끝점의 URL을 확인합니다.
$ openstack catalog list명령에서 반환하는 각 HTTPS 끝점의 URL을 기록합니다.
각 공용 엔드포인트에 대해 호스트와 포트를 기록해 둡니다.
작은 정보스키마, 포트 및 경로를 제거하여 끝점의 호스트를 결정합니다.
각 끝점에 다음 명령을 실행하여 인증서의 SAN 필드를 추출합니다.
호스트변수를 설정합니다.$ host=<host_name>포트변수를 설정합니다.$ port=<port_number>$ openssl s_client -showcerts -servername "$host" -connect "$host:$port" </dev/null 2>/dev/null \ | openssl x509 -noout -ext subjectAltNameX509v3 Subject Alternative Name: DNS:your.host.example.net
x509: certificate relies on legacy Common Name field, use SANs instead2장.
2.1.
2.1.1.
2.1.2.
2.2.
2.2.1.
- 참고
$ openstack network create radio --provider-physical-network radio --provider-network-type flat --external$ openstack network create uplink --provider-physical-network uplink --provider-network-type vlan --external$ openstack subnet create --network radio --subnet-range <radio_network_subnet_range> radio$ openstack subnet create --network uplink --subnet-range <uplink_network_subnet_range> uplink
2.3.
2.4.
3장.
3.1.
3.2.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3.2.1.
3.2.2.
3.2.3.
3.2.4.
- 중요
Expand 표 3.2. 참고 - 작은 정보
Expand 표 3.3. 참고
3.2.4.1.
예 3.1.
global
log 127.0.0.1 local2
pidfile /var/run/haproxy.pid
maxconn 4000
daemon
defaults
mode http
log global
option dontlognull
option http-server-close
option redispatch
retries 3
timeout http-request 10s
timeout queue 1m
timeout connect 10s
timeout client 1m
timeout server 1m
timeout http-keep-alive 10s
timeout check 10s
maxconn 3000
listen api-server-6443
bind *:6443
mode tcp
option httpchk GET /readyz HTTP/1.0
option log-health-checks
balance roundrobin
server bootstrap bootstrap.ocp4.example.com:6443 verify none check check-ssl inter 10s fall 2 rise 3 backup
server master0 master0.ocp4.example.com:6443 weight 1 verify none check check-ssl inter 10s fall 2 rise 3
server master1 master1.ocp4.example.com:6443 weight 1 verify none check check-ssl inter 10s fall 2 rise 3
server master2 master2.ocp4.example.com:6443 weight 1 verify none check check-ssl inter 10s fall 2 rise 3
listen machine-config-server-22623
bind *:22623
mode tcp
server bootstrap bootstrap.ocp4.example.com:22623 check inter 1s backup
server master0 master0.ocp4.example.com:22623 check inter 1s
server master1 master1.ocp4.example.com:22623 check inter 1s
server master2 master2.ocp4.example.com:22623 check inter 1s
listen ingress-router-443
bind *:443
mode tcp
balance source
server compute0 compute0.ocp4.example.com:443 check inter 1s
server compute1 compute1.ocp4.example.com:443 check inter 1s
listen ingress-router-80
bind *:80
mode tcp
balance source
server compute0 compute0.ocp4.example.com:80 check inter 1s
server compute1 compute1.ocp4.example.com:80 check inter 1s
3.3.
3.4.
$ openstack role add --user <user> --project <project> swiftoperator
3.5.
apiVersion: storage.k8s.io/v1 kind: StorageClass metadata: name: custom-csi-storageclass provisioner: cinder.csi.openstack.org volumeBindingMode: WaitForFirstConsumer allowVolumeExpansion: true parameters: availability: <availability_zone_name>참고$ oc apply -f <storage_class_file_name>storageclass.storage.k8s.io/custom-csi-storageclass createdapiVersion: v1 kind: PersistentVolumeClaim metadata: name: csi-pvc-imageregistry namespace: openshift-image-registry1 annotations: imageregistry.openshift.io: "true" spec: accessModes: - ReadWriteOnce volumeMode: Filesystem resources: requests: storage: 100Gi2 storageClassName: <your_custom_storage_class>3 $ oc apply -f <pvc_file_name>persistentvolumeclaim/csi-pvc-imageregistry created$ oc patch configs.imageregistry.operator.openshift.io/cluster --type 'json' -p='[{"op": "replace", "path": "/spec/storage/pvc/claim", "value": "csi-pvc-imageregistry"}]'config.imageregistry.operator.openshift.io/cluster patched
$ oc get configs.imageregistry.operator.openshift.io/cluster -o yaml... status: ... managementState: Managed pvc: claim: csi-pvc-imageregistry ...$ oc get pvc -n openshift-image-registry csi-pvc-imageregistryNAME STATUS VOLUME CAPACITY ACCESS MODES STORAGECLASS AGE csi-pvc-imageregistry Bound pvc-72a8f9c9-f462-11e8-b6b6-fa163e18b7b5 100Gi RWO custom-csi-storageclass 11m
3.6.
$ openstack network list --long -c ID -c Name -c "Router Type"+--------------------------------------+----------------+-------------+ | ID | Name | Router Type | +--------------------------------------+----------------+-------------+ | 148a8023-62a7-4672-b018-003462f8d7dc | public_network | External | +--------------------------------------+----------------+-------------+
|
|
|
|
|
|
|
|
|
3.7.
- 중요
clouds: shiftstack: auth: auth_url: http://10.10.14.42:5000/v3 project_name: shiftstack username: <username> password: <password> user_domain_name: Default project_domain_name: Default dev-env: region_name: RegionOne auth: username: <username> password: <password> project_name: 'devonly' auth_url: 'https://10.10.14.22:5001/v2.0'
clouds: shiftstack: ... cacert: "/etc/pki/ca-trust/source/anchors/ca.crt.pem"작은 정보$ oc edit configmap -n openshift-config cloud-provider-config
3.8.
$ openshift-install --dir <destination_directory> create manifests$ vi openshift/manifests/cloud-provider-config.yaml#... [LoadBalancer] lb-provider = "amphora"1 floating-network-id="d3deb660-4190-40a3-91f1-37326fe6ec4a"2 create-monitor = True3 monitor-delay = 10s4 monitor-timeout = 10s5 monitor-max-retries = 16 #...중요중요- 작은 정보
$ oc edit configmap -n openshift-config cloud-provider-config
3.9.
- 중요
$ tar -xvf openshift-install-linux.tar.gz
3.10.
$ ./openshift-install create install-config --dir <installation_directory>1 - 참고
- 중요
3.10.1.
- 참고
apiVersion: v1 baseDomain: my.domain.com proxy: httpProxy: http://<username>:<pswd>@<ip>:<port>1 httpsProxy: https://<username>:<pswd>@<ip>:<port>2 noProxy: example.com3 additionalTrustBundle: |4 -----BEGIN CERTIFICATE----- <MY_TRUSTED_CA_CERT> -----END CERTIFICATE----- additionalTrustBundlePolicy: <policy_to_add_additionalTrustBundle>5 참고참고$ ./openshift-install wait-for install-complete --log-level debug
3.10.2.
3.10.3.
$ ./openshift-install wait-for install-complete --log-level debug3.10.4.
[D]
3.10.4.1.
- 작은 정보
- 작은 정보
$ openstack network create --project openshift$ openstack subnet create --project openshift중요 $ openstack subnet create --dhcp --host-route destination=169.254.169.254/32,gateway=192.0.2.2 ...
3.10.4.2.
...
platform:
openstack:
apiVIPs:
- 192.0.2.13
ingressVIPs:
- 192.0.2.23
machinesSubnet: fa806b2f-ac49-4bce-b9db-124bc64209bf
# ...
networking:
machineNetwork:
- cidr: 192.0.2.0/24
3.10.5.
예 3.2.
apiVersion: v1
baseDomain: example.com
controlPlane:
name: master
platform: {}
replicas: 3
compute:
- name: worker
platform:
openstack:
type: ml.large
replicas: 3
metadata:
name: example
networking:
clusterNetwork:
- cidr: 10.128.0.0/14
hostPrefix: 23
machineNetwork:
- cidr: 10.0.0.0/16
serviceNetwork:
- 172.30.0.0/16
networkType: OVNKubernetes
platform:
openstack:
cloud: mycloud
externalNetwork: external
computeFlavor: m1.xlarge
apiFloatingIP: 128.0.0.1
fips: false
pullSecret: '{"auths": ...}'
sshKey: ssh-ed25519 AAAA...예 3.3.
apiVersion: v1
baseDomain: example.com
controlPlane:
name: master
platform: {}
replicas: 3
compute:
- name: worker
platform:
openstack:
type: ml.large
replicas: 3
metadata:
name: example
networking:
clusterNetwork:
- cidr: 10.128.0.0/14
hostPrefix: 23
- cidr: fd01::/48
hostPrefix: 64
machineNetwork:
- cidr: 192.168.25.0/24
- cidr: fd2e:6f44:5dd8:c956::/64
serviceNetwork:
- 172.30.0.0/16
- fd02::/112
networkType: OVNKubernetes
platform:
openstack:
cloud: mycloud
externalNetwork: external
computeFlavor: m1.xlarge
apiVIPs:
- 192.168.25.10
- fd2e:6f44:5dd8:c956:f816:3eff:fec3:5955
ingressVIPs:
- 192.168.25.132
- fd2e:6f44:5dd8:c956:f816:3eff:fe40:aecb
controlPlanePort:
fixedIPs:
- subnet:
name: openshift-dual4
- subnet:
name: openshift-dual6
network:
name: openshift-dual
fips: false
pullSecret: '{"auths": ...}'
sshKey: ssh-ed25519 AAAA...3.10.6.
3.10.6.1.
- 참고
apiVersion: v1 baseDomain: mydomain.test compute: - name: worker platform: openstack: type: m1.xlarge replicas: 3 controlPlane: name: master platform: openstack: type: m1.xlarge replicas: 3 metadata: name: mycluster networking: machineNetwork:1 - cidr: "192.168.25.0/24" - cidr: "fd2e:6f44:5dd8:c956::/64" clusterNetwork:2 - cidr: 10.128.0.0/14 hostPrefix: 23 - cidr: fd01::/48 hostPrefix: 64 serviceNetwork:3 - 172.30.0.0/16 - fd02::/112 platform: openstack: ingressVIPs: ['192.168.25.79', 'fd2e:6f44:5dd8:c956:f816:3eff:fef1:1bad']4 apiVIPs: ['192.168.25.199', 'fd2e:6f44:5dd8:c956:f816:3eff:fe78:cf36']5 controlPlanePort:6 fixedIPs:7 - subnet:8 name: subnet-v4 id: subnet-v4-id - subnet:9 name: subnet-v6 id: subnet-v6-id network:10 name: dualstack id: network-idapiVersion: v1 baseDomain: mydomain.test compute: - name: worker platform: openstack: type: m1.xlarge replicas: 3 controlPlane: name: master platform: openstack: type: m1.xlarge replicas: 3 metadata: name: mycluster networking: machineNetwork:1 - cidr: "fd2e:6f44:5dd8:c956::/64" - cidr: "192.168.25.0/24" clusterNetwork:2 - cidr: fd01::/48 hostPrefix: 64 - cidr: 10.128.0.0/14 hostPrefix: 23 serviceNetwork:3 - fd02::/112 - 172.30.0.0/16 platform: openstack: ingressVIPs: ['fd2e:6f44:5dd8:c956:f816:3eff:fef1:1bad', '192.168.25.79']4 apiVIPs: ['fd2e:6f44:5dd8:c956:f816:3eff:fe78:cf36', '192.168.25.199']5 controlPlanePort:6 fixedIPs:7 - subnet:8 name: subnet-v6 id: subnet-v6-id - subnet:9 name: subnet-v4 id: subnet-v4-id network:10 name: dualstack id: network-id
[connection] type=ethernet [ipv6] addr-gen-mode=eui64 method=auto
[connection] ipv6.addr-gen-mode=0
3.10.7.
apiVersion: v1
baseDomain: mydomain.test
compute:
- name: worker
platform:
openstack:
type: m1.xlarge
replicas: 3
controlPlane:
name: master
platform:
openstack:
type: m1.xlarge
replicas: 3
metadata:
name: mycluster
networking:
clusterNetwork:
- cidr: 10.128.0.0/14
hostPrefix: 23
machineNetwork:
- cidr: 192.168.10.0/24
platform:
openstack:
cloud: mycloud
machinesSubnet: 8586bf1a-cc3c-4d40-bdf6-c243decc603a
apiVIPs:
- 192.168.10.5
ingressVIPs:
- 192.168.10.7
loadBalancer:
type: UserManaged 3.11.
$ ssh-keygen -t ed25519 -N '' -f <path>/<file_name>1 참고$ cat <path>/<file_name>.pub$ cat ~/.ssh/id_ed25519.pub- 참고
$ eval "$(ssh-agent -s)"Agent pid 31874참고
$ ssh-add <path>/<file_name>1 Identity added: /home/<you>/<path>/<file_name> (<computer_name>)
3.12.
3.12.1.
$ openstack floating ip create --description "API <cluster_name>.<base_domain>" <external_network>$ openstack floating ip create --description "Ingress <cluster_name>.<base_domain>" <external_network>api.<cluster_name>.<base_domain>. IN A <API_FIP> *.apps.<cluster_name>.<base_domain>. IN A <apps_FIP>참고
3.12.2.
api.<cluster_name>.<base_domain>. IN A <api_port_IP>
*.apps.<cluster_name>.<base_domain>. IN A <ingress_port_IP>
3.13.
...
INFO Install complete!
INFO To access the cluster as the system:admin user when using 'oc', run 'export KUBECONFIG=/home/myuser/install_dir/auth/kubeconfig'
INFO Access the OpenShift web-console here: https://console-openshift-console.apps.mycluster.example.com
INFO Login to the console with user: "kubeadmin", and password: "password"
INFO Time elapsed: 36m22s3.14.
$ export KUBECONFIG=<installation_directory>/auth/kubeconfig1 $ oc get nodes$ oc get clusterversion$ oc get clusteroperator$ oc get pods -A
3.15.
$ export KUBECONFIG=<installation_directory>/auth/kubeconfig1 $ oc whoamisystem:admin
3.16.
3.17.
4장.
4.1.
4.2.
4.3.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4.3.1.
4.3.2.
4.3.3.
4.4.
$ sudo subscription-manager register # If not done already$ sudo subscription-manager attach --pool=$YOUR_POOLID # If not done already$ sudo subscription-manager repos --disable=* # If not done already$ sudo subscription-manager repos \ --enable=rhel-8-for-x86_64-baseos-rpms \ --enable=openstack-16-tools-for-rhel-8-x86_64-rpms \ --enable=ansible-2.9-for-rhel-8-x86_64-rpms \ --enable=rhel-8-for-x86_64-appstream-rpms
$ sudo yum install python3-openstackclient ansible python3-openstacksdk python3-netaddr ansible-collections-openstack$ sudo alternatives --set python /usr/bin/python3
4.5.
$ xargs -n 1 curl -O <<< ' https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/bootstrap.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/common.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/compute-nodes.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/control-plane.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/down-bootstrap.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/down-compute-nodes.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/down-control-plane.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/down-network.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/down-security-groups.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/down-containers.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/inventory.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/network.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/security-groups.yaml https://raw.githubusercontent.com/openshift/installer/release-4.15/upi/openstack/update-network-resources.yaml'
4.6.
- 중요
$ tar -xvf openshift-install-linux.tar.gz
4.7.
$ ssh-keygen -t ed25519 -N '' -f <path>/<file_name>1 참고$ cat <path>/<file_name>.pub$ cat ~/.ssh/id_ed25519.pub- 참고
$ eval "$(ssh-agent -s)"Agent pid 31874참고
$ ssh-add <path>/<file_name>1 Identity added: /home/<you>/<path>/<file_name> (<computer_name>)
4.8.
- 중요
- 참고
$ file <name_of_downloaded_file> $ openstack image create --container-format=bare --disk-format=qcow2 --file rhcos-${RHCOS_VERSION}-openstack.qcow2 rhcos중요주의
4.9.
$ openstack network list --long -c ID -c Name -c "Router Type"+--------------------------------------+----------------+-------------+ | ID | Name | Router Type | +--------------------------------------+----------------+-------------+ | 148a8023-62a7-4672-b018-003462f8d7dc | public_network | External | +--------------------------------------+----------------+-------------+
4.10.
4.10.1.
$ openstack floating ip create --description "API <cluster_name>.<base_domain>" <external_network>$ openstack floating ip create --description "Ingress <cluster_name>.<base_domain>" <external_network>$ openstack floating ip create --description "bootstrap machine" <external_network>api.<cluster_name>.<base_domain>. IN A <API_FIP> *.apps.<cluster_name>.<base_domain>. IN A <apps_FIP>참고
4.10.2.
api.<cluster_name>.<base_domain>. IN A <api_port_IP>
*.apps.<cluster_name>.<base_domain>. IN A <ingress_port_IP>
4.11.
- 중요
clouds: shiftstack: auth: auth_url: http://10.10.14.42:5000/v3 project_name: shiftstack username: <username> password: <password> user_domain_name: Default project_domain_name: Default dev-env: region_name: RegionOne auth: username: <username> password: <password> project_name: 'devonly' auth_url: 'https://10.10.14.22:5001/v2.0'
clouds: shiftstack: ... cacert: "/etc/pki/ca-trust/source/anchors/ca.crt.pem"작은 정보$ oc edit configmap -n openshift-config cloud-provider-config
4.12.
$ ansible-playbook -i inventory.yaml network.yaml참고참고
4.13.
$ ./openshift-install create install-config --dir <installation_directory>1 - 참고
- 중요
4.13.1.
4.13.2.
예 4.1.
apiVersion: v1
baseDomain: example.com
controlPlane:
name: master
platform: {}
replicas: 3
compute:
- name: worker
platform:
openstack:
type: ml.large
replicas: 3
metadata:
name: example
networking:
clusterNetwork:
- cidr: 10.128.0.0/14
hostPrefix: 23
machineNetwork:
- cidr: 10.0.0.0/16
serviceNetwork:
- 172.30.0.0/16
networkType: OVNKubernetes
platform:
openstack:
cloud: mycloud
externalNetwork: external
computeFlavor: m1.xlarge
apiFloatingIP: 128.0.0.1
fips: false
pullSecret: '{"auths": ...}'
sshKey: ssh-ed25519 AAAA...예 4.2.
apiVersion: v1
baseDomain: example.com
controlPlane:
name: master
platform: {}
replicas: 3
compute:
- name: worker
platform:
openstack:
type: ml.large
replicas: 3
metadata:
name: example
networking:
clusterNetwork:
- cidr: 10.128.0.0/14
hostPrefix: 23
- cidr: fd01::/48
hostPrefix: 64
machineNetwork:
- cidr: 192.168.25.0/24
- cidr: fd2e:6f44:5dd8:c956::/64
serviceNetwork:
- 172.30.0.0/16
- fd02::/112
networkType: OVNKubernetes
platform:
openstack:
cloud: mycloud
externalNetwork: external
computeFlavor: m1.xlarge
apiVIPs:
- 192.168.25.10
- fd2e:6f44:5dd8:c956:f816:3eff:fec3:5955
ingressVIPs:
- 192.168.25.132
- fd2e:6f44:5dd8:c956:f816:3eff:fe40:aecb
controlPlanePort:
fixedIPs:
- subnet:
name: openshift-dual4
- subnet:
name: openshift-dual6
network:
name: openshift-dual
fips: false
pullSecret: '{"auths": ...}'
sshKey: ssh-ed25519 AAAA...4.13.3.
$ python -c 'import yaml path = "install-config.yaml" data = yaml.safe_load(open(path)) inventory = yaml.safe_load(open("inventory.yaml"))["all"]["hosts"]["localhost"] machine_net = [{"cidr": inventory["os_subnet_range"]}] api_vips = [inventory["os_apiVIP"]] ingress_vips = [inventory["os_ingressVIP"]] ctrl_plane_port = {"network": {"name": inventory["os_network"]}, "fixedIPs": [{"subnet": {"name": inventory["os_subnet"]}}]} if inventory.get("os_subnet6"):1 machine_net.append({"cidr": inventory["os_subnet6_range"]}) api_vips.append(inventory["os_apiVIP6"]) ingress_vips.append(inventory["os_ingressVIP6"]) data["networking"]["networkType"] = "OVNKubernetes" data["networking"]["clusterNetwork"].append({"cidr": inventory["cluster_network6_cidr"], "hostPrefix": inventory["cluster_network6_prefix"]}) data["networking"]["serviceNetwork"].append(inventory["service_subnet6_range"]) ctrl_plane_port["fixedIPs"].append({"subnet": {"name": inventory["os_subnet6"]}}) data["networking"]["machineNetwork"] = machine_net data["platform"]["openstack"]["apiVIPs"] = api_vips data["platform"]["openstack"]["ingressVIPs"] = ingress_vips data["platform"]["openstack"]["controlPlanePort"] = ctrl_plane_port del data["platform"]["openstack"]["externalDNS"] open(path, "w").write(yaml.dump(data, default_flow_style=False))'
4.13.4.
$ python -c ' import yaml; path = "install-config.yaml"; data = yaml.safe_load(open(path)); data["compute"][0]["replicas"] = 0; open(path, "w").write(yaml.dump(data, default_flow_style=False))'
4.13.5.
[D]
4.13.5.1.
- 작은 정보
- 작은 정보
$ openstack network create --project openshift$ openstack subnet create --project openshift중요 $ openstack subnet create --dhcp --host-route destination=169.254.169.254/32,gateway=192.0.2.2 ...
4.13.5.2.
...
platform:
openstack:
apiVIPs:
- 192.0.2.13
ingressVIPs:
- 192.0.2.23
machinesSubnet: fa806b2f-ac49-4bce-b9db-124bc64209bf
# ...
networking:
machineNetwork:
- cidr: 192.0.2.0/24
4.14.
$ ./openshift-install create manifests --dir <installation_directory>1 $ rm -f openshift/99_openshift-cluster-api_master-machines-*.yaml openshift/99_openshift-cluster-api_worker-machineset-*.yaml openshift/99_openshift-machine-api_master-control-plane-machine-set.yaml$ ./openshift-install create ignition-configs --dir <installation_directory>1 . ├── auth │ ├── kubeadmin-password │ └── kubeconfig ├── bootstrap.ign ├── master.ign ├── metadata.json └── worker.ign$ export INFRA_ID=$(jq -r .infraID metadata.json)
4.15.
import base64 import json import os with open('bootstrap.ign', 'r') as f: ignition = json.load(f) files = ignition['storage'].get('files', []) infra_id = os.environ.get('INFRA_ID', 'openshift').encode() hostname_b64 = base64.standard_b64encode(infra_id + b'-bootstrap\n').decode().strip() files.append( { 'path': '/etc/hostname', 'mode': 420, 'contents': { 'source': 'data:text/plain;charset=utf-8;base64,' + hostname_b64 } }) ca_cert_path = os.environ.get('OS_CACERT', '') if ca_cert_path: with open(ca_cert_path, 'r') as f: ca_cert = f.read().encode() ca_cert_b64 = base64.standard_b64encode(ca_cert).decode().strip() files.append( { 'path': '/opt/openshift/tls/cloud-ca-cert.pem', 'mode': 420, 'contents': { 'source': 'data:text/plain;charset=utf-8;base64,' + ca_cert_b64 } }) ignition['storage']['files'] = files; with open('bootstrap.ign', 'w') as f: json.dump(ignition, f)$ openstack image create --disk-format=raw --container-format=bare --file bootstrap.ign <image_name>$ openstack image show <image_name>참고$ openstack catalog show image$ openstack token issue -c id -f value{ "ignition": { "config": { "merge": [{ "source": "<storage_url>",1 "httpHeaders": [{ "name": "X-Auth-Token",2 "value": "<token_ID>"3 }] }] }, "security": { "tls": { "certificateAuthorities": [{ "source": "data:text/plain;charset=utf-8;base64,<base64_encoded_certificate>"4 }] } }, "version": "3.2.0" } }
4.16.
$ for index in $(seq 0 2); do MASTER_HOSTNAME="$INFRA_ID-master-$index\n" python -c "import base64, json, sys; ignition = json.load(sys.stdin); storage = ignition.get('storage', {}); files = storage.get('files', []); files.append({'path': '/etc/hostname', 'mode': 420, 'contents': {'source': 'data:text/plain;charset=utf-8;base64,' + base64.standard_b64encode(b'$MASTER_HOSTNAME').decode().strip(), 'verification': {}}, 'filesystem': 'root'}); storage['files'] = files; ignition['storage'] = storage json.dump(ignition, sys.stdout)" <master.ign >"$INFRA_ID-master-$index-ignition.json" done
4.17.
... # The public network providing connectivity to the cluster. If not # provided, the cluster external connectivity must be provided in another # way. # Required for os_api_fip, os_ingress_fip, os_bootstrap_fip. os_external_network: 'external' ...중요... # OpenShift API floating IP address. If this value is non-empty, the # corresponding floating IP will be attached to the Control Plane to # serve the OpenShift API. os_api_fip: '203.0.113.23' # OpenShift Ingress floating IP address. If this value is non-empty, the # corresponding floating IP will be attached to the worker nodes to serve # the applications. os_ingress_fip: '203.0.113.19' # If this value is non-empty, the corresponding floating IP will be # attached to the bootstrap machine. This is needed for collecting logs # in case of install failure. os_bootstrap_fip: '203.0.113.20'중요$ ansible-playbook -i inventory.yaml security-groups.yaml$ ansible-playbook -i inventory.yaml update-network-resources.yaml1 $ openstack subnet set --dns-nameserver <server_1> --dns-nameserver <server_2> "$INFRA_ID-nodes"
4.17.1.
all: hosts: localhost: ansible_connection: local ansible_python_interpreter: "{{ansible_playbook_python}}" # User-provided values os_subnet_range: '10.0.0.0/16' os_flavor_master: 'my-bare-metal-flavor'1 os_flavor_worker: 'my-bare-metal-flavor'2 os_image_rhcos: 'rhcos' os_external_network: 'external' ...
$ ./openshift-install wait-for install-complete --log-level debug4.18.
$ ansible-playbook -i inventory.yaml bootstrap.yaml$ openstack console log show "$INFRA_ID-bootstrap"
4.19.
$ ansible-playbook -i inventory.yaml control-plane.yaml$ openshift-install wait-for bootstrap-completeINFO API v1.28.5 up INFO Waiting up to 30m0s for bootstrapping to complete... ... INFO It is now safe to remove the bootstrap resources
4.20.
$ export KUBECONFIG=<installation_directory>/auth/kubeconfig1 $ oc whoamisystem:admin
4.21.
$ ansible-playbook -i inventory.yaml down-bootstrap.yaml
4.22.
$ ansible-playbook -i inventory.yaml compute-nodes.yaml
4.23.
$ oc get nodesNAME STATUS ROLES AGE VERSION master-0 Ready master 63m v1.28.5 master-1 Ready master 63m v1.28.5 master-2 Ready master 64m v1.28.5참고$ oc get csrNAME AGE REQUESTOR CONDITION csr-8b2br 15m system:serviceaccount:openshift-machine-config-operator:node-bootstrapper Pending csr-8vnps 15m system:serviceaccount:openshift-machine-config-operator:node-bootstrapper Pending ...- 참고참고
$ oc adm certificate approve <csr_name>1 $ oc get csr -o go-template='{{range .items}}{{if not .status}}{{.metadata.name}}{{"\n"}}{{end}}{{end}}' | xargs --no-run-if-empty oc adm certificate approve참고
$ oc get csrNAME AGE REQUESTOR CONDITION csr-bfd72 5m26s system:node:ip-10-0-50-126.us-east-2.compute.internal Pending csr-c57lv 5m26s system:node:ip-10-0-95-157.us-east-2.compute.internal Pending ...$ oc adm certificate approve <csr_name>1 $ oc get csr -o go-template='{{range .items}}{{if not .status}}{{.metadata.name}}{{"\n"}}{{end}}{{end}}' | xargs oc adm certificate approve
$ oc get nodesNAME STATUS ROLES AGE VERSION master-0 Ready master 73m v1.28.5 master-1 Ready master 73m v1.28.5 master-2 Ready master 74m v1.28.5 worker-0 Ready worker 11m v1.28.5 worker-1 Ready worker 11m v1.28.5참고
4.24.
$ openshift-install --log-level debug wait-for install-complete
4.25.
4.26.
5장.
5.1.
- 중요
5.2.
5.2.1.
5.3.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5.3.1.
5.3.2.
5.3.3.
5.4.
5.5.
$ openstack role add --user <user> --project <project> swiftoperator
5.6.
- 중요
clouds: shiftstack: auth: auth_url: http://10.10.14.42:5000/v3 project_name: shiftstack username: <username> password: <password> user_domain_name: Default project_domain_name: Default dev-env: region_name: RegionOne auth: username: <username> password: <password> project_name: 'devonly' auth_url: 'https://10.10.14.22:5001/v2.0'
clouds: shiftstack: ... cacert: "/etc/pki/ca-trust/source/anchors/ca.crt.pem"작은 정보$ oc edit configmap -n openshift-config cloud-provider-config
5.7.
$ openshift-install --dir <destination_directory> create manifests$ vi openshift/manifests/cloud-provider-config.yaml#... [LoadBalancer] lb-provider = "amphora"1 floating-network-id="d3deb660-4190-40a3-91f1-37326fe6ec4a"2 create-monitor = True3 monitor-delay = 10s4 monitor-timeout = 10s5 monitor-max-retries = 16 #...중요중요- 작은 정보
$ oc edit configmap -n openshift-config cloud-provider-config
5.8.
- 중요
- 참고
$ file <name_of_downloaded_file> $ openstack image create --file rhcos-44.81.202003110027-0-openstack.x86_64.qcow2 --disk-format qcow2 rhcos-${RHCOS_VERSION}중요주의
5.9.
$ ./openshift-install create install-config --dir <installation_directory>1 - 참고
platform: openstack: clusterOSImage: http://mirror.example.com/images/rhcos-43.81.201912131630.0-openstack.x86_64.qcow2.gz?sha256=ffebbd68e8a1f2a245ca19522c16c86f67f9ac8e4e0c1f0a812b068b16f7265dpullSecret: '{"auths":{"<mirror_host_name>:5000": {"auth": "<credentials>","email": "you@example.com"}}}'additionalTrustBundle: | -----BEGIN CERTIFICATE----- ZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZ -----END CERTIFICATE-----imageContentSources: - mirrors: - <mirror_host_name>:5000/<repo_name>/release source: quay.io/openshift-release-dev/ocp-release - mirrors: - <mirror_host_name>:5000/<repo_name>/release source: registry.redhat.io/ocp/releasepublish: Internal
- 중요
5.9.1.
- 참고
apiVersion: v1 baseDomain: my.domain.com proxy: httpProxy: http://<username>:<pswd>@<ip>:<port>1 httpsProxy: https://<username>:<pswd>@<ip>:<port>2 noProxy: example.com3 additionalTrustBundle: |4 -----BEGIN CERTIFICATE----- <MY_TRUSTED_CA_CERT> -----END CERTIFICATE----- additionalTrustBundlePolicy: <policy_to_add_additionalTrustBundle>5 참고참고$ ./openshift-install wait-for install-complete --log-level debug
5.9.2.
apiVersion: v1
baseDomain: example.com
controlPlane:
name: master
platform: {}
replicas: 3
compute:
- name: worker
platform:
openstack:
type: ml.large
replicas: 3
metadata:
name: example
networking:
clusterNetwork:
- cidr: 10.128.0.0/14
hostPrefix: 23
machineNetwork:
- cidr: 10.0.0.0/16
serviceNetwork:
- 172.30.0.0/16
networkType: OVNKubernetes
platform:
openstack:
region: region1
cloud: mycloud
externalNetwork: external
computeFlavor: m1.xlarge
apiFloatingIP: 128.0.0.1
fips: false
pullSecret: '{"auths": ...}'
sshKey: ssh-ed25519 AAAA...
additionalTrustBundle: |
-----BEGIN CERTIFICATE-----
ZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZ
-----END CERTIFICATE-----
imageContentSources:
- mirrors:
- <mirror_registry>/<repo_name>/release
source: quay.io/openshift-release-dev/ocp-release
- mirrors:
- <mirror_registry>/<repo_name>/release
source: quay.io/openshift-release-dev/ocp-v4.0-art-dev5.10.
$ ssh-keygen -t ed25519 -N '' -f <path>/<file_name>1 참고$ cat <path>/<file_name>.pub$ cat ~/.ssh/id_ed25519.pub- 참고
$ eval "$(ssh-agent -s)"Agent pid 31874참고
$ ssh-add <path>/<file_name>1 Identity added: /home/<you>/<path>/<file_name> (<computer_name>)
5.11.
5.11.1.
$ openstack floating ip create --description "API <cluster_name>.<base_domain>" <external_network>$ openstack floating ip create --description "Ingress <cluster_name>.<base_domain>" <external_network>api.<cluster_name>.<base_domain>. IN A <API_FIP> *.apps.<cluster_name>.<base_domain>. IN A <apps_FIP>참고
5.11.2.
api.<cluster_name>.<base_domain>. IN A <api_port_IP>
*.apps.<cluster_name>.<base_domain>. IN A <ingress_port_IP>
5.12.
...
INFO Install complete!
INFO To access the cluster as the system:admin user when using 'oc', run 'export KUBECONFIG=/home/myuser/install_dir/auth/kubeconfig'
INFO Access the OpenShift web-console here: https://console-openshift-console.apps.mycluster.example.com
INFO Login to the console with user: "kubeadmin", and password: "password"
INFO Time elapsed: 36m22s5.13.
$ export KUBECONFIG=<installation_directory>/auth/kubeconfig1 $ oc get nodes$ oc get clusterversion$ oc get clusteroperator$ oc get pods -A
5.14.
$ export KUBECONFIG=<installation_directory>/auth/kubeconfig1 $ oc whoamisystem:admin
5.15.
$ oc patch OperatorHub cluster --type json \ -p '[{"op": "add", "path": "/spec/disableAllDefaultSources", "value": true}]'
5.16.
5.17.
6장.
6.1.
$ openstack port show <cluster_name>-<cluster_ID>-ingress-port$ openstack floating ip set --port <ingress_port_ID> <apps_FIP>*.apps.<cluster_name>.<base_domain> IN A <apps_FIP>
<apps_FIP> console-openshift-console.apps.<cluster name>.<base domain>
<apps_FIP> integrated-oauth-server-openshift-authentication.apps.<cluster name>.<base domain>
<apps_FIP> oauth-openshift.apps.<cluster name>.<base domain>
<apps_FIP> prometheus-k8s-openshift-monitoring.apps.<cluster name>.<base domain>
<apps_FIP> <app name>.apps.<cluster name>.<base domain>6.2.
apiVersion: sriovnetwork.openshift.io/v1 kind: SriovNetworkNodePolicy1 metadata: name: "hwoffload9" namespace: openshift-sriov-network-operator spec: deviceType: netdevice isRdma: true nicSelector: pfNames:2 - ens6 nodeSelector: feature.node.kubernetes.io/network-sriov.capable: 'true' numVfs: 1 priority: 99 resourceName: "hwoffload9"apiVersion: sriovnetwork.openshift.io/v1 kind: SriovNetworkNodePolicy1 metadata: name: "hwoffload10" namespace: openshift-sriov-network-operator spec: deviceType: netdevice isRdma: true nicSelector: pfNames:2 - ens5 nodeSelector: feature.node.kubernetes.io/network-sriov.capable: 'true' numVfs: 1 priority: 99 resourceName: "hwoffload10"apiVersion: k8s.cni.cncf.io/v1 kind: NetworkAttachmentDefinition metadata: annotations: k8s.v1.cni.cncf.io/resourceName: openshift.io/hwoffload9 name: hwoffload9 namespace: default spec: config: '{ "cniVersion":"0.3.1", "name":"hwoffload9","type":"host-device","device":"ens6" }'apiVersion: k8s.cni.cncf.io/v1 kind: NetworkAttachmentDefinition metadata: annotations: k8s.v1.cni.cncf.io/resourceName: openshift.io/hwoffload10 name: hwoffload10 namespace: default spec: config: '{ "cniVersion":"0.3.1", "name":"hwoffload10","type":"host-device","device":"ens5" }'apiVersion: v1 kind: Pod metadata: name: dpdk-testpmd namespace: default annotations: irq-load-balancing.crio.io: disable cpu-quota.crio.io: disable k8s.v1.cni.cncf.io/resourceName: openshift.io/hwoffload9 k8s.v1.cni.cncf.io/resourceName: openshift.io/hwoffload10 spec: restartPolicy: Never containers: - name: dpdk-testpmd image: quay.io/krister/centos8_nfv-container-dpdk-testpmd:latest
6.3.
spec: additionalNetworks: - name: hwoffload1 namespace: cnf rawCNIConfig: '{ "cniVersion": "0.3.1", "name": "hwoffload1", "type": "host-device","pciBusId": "0000:00:05.0", "ipam": {}}'1 type: Raw$ oc describe SriovNetworkNodeState -n openshift-sriov-network-operator
$ oc apply -f network.yaml
6.4.
6.5.
apiVersion: apps/v1 kind: Deployment metadata: name: hello-openshift namespace: ipv6 spec: affinity: podAntiAffinity: requiredDuringSchedulingIgnoredDuringExecution: - labelSelector: matchExpressions: - key: app operator: In values: - hello-openshift replicas: 2 selector: matchLabels: app: hello-openshift template: metadata: labels: app: hello-openshift annotations: k8s.v1.cni.cncf.io/networks: ipv6 spec: securityContext: runAsNonRoot: true seccompProfile: type: RuntimeDefault containers: - name: hello-openshift securityContext: allowPrivilegeEscalation: false capabilities: drop: - ALL image: quay.io/openshift/origin-hello-openshift ports: - containerPort: 8080$ oc create -f <ipv6_enabled_resource>1
6.6.
$ oc edit networks.operator.openshift.io cluster... spec: additionalNetworks: - name: ipv6 namespace: ipv61 rawCNIConfig: '{ "cniVersion": "0.3.1", "name": "ipv6", "type": "macvlan", "master": "ens4"}'2 type: Raw참고
$ oc get network-attachment-definitions -ANAMESPACE NAME AGE ipv6 ipv6 21h
7장.
7.1.
[Global]
use-clouds = true
clouds-file = /etc/openstack/secret/clouds.yaml
cloud = openstack
...
[LoadBalancer]
enabled = true
7.2.
apiVersion: v1
data:
cloud.conf: |
[Global]
secret-name = openstack-credentials
secret-namespace = kube-system
region = regionOne
[LoadBalancer]
enabled = True
kind: ConfigMap
metadata:
creationTimestamp: "2022-12-20T17:01:08Z"
name: cloud-conf
namespace: openshift-cloud-controller-manager
resourceVersion: "2519"
uid: cbbeedaf-41ed-41c2-9f37-4885732d3677
7.2.1.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7.2.2.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8장.
8.1.
$ openstack flavor create --<ram 16384> --<disk 0> --ephemeral 10 --vcpus 4 <flavor_name># ... controlPlane: name: master platform: openstack: type: ${CONTROL_PLANE_FLAVOR} rootVolume: size: 25 types: - ${CINDER_TYPE} replicas: 3 # ...$ openshift-install create cluster --dir <installation_directory>1 $ oc wait clusteroperators --all --for=condition=Progressing=false1 $ oc patch ControlPlaneMachineSet/cluster -n openshift-machine-api --type json -p '1 [ { "op": "add", "path": "/spec/template/machines_v1beta1_machine_openshift_io/spec/providerSpec/value/additionalBlockDevices",2 "value": [ { "name": "etcd", "sizeGiB": 10, "storage": { "type": "Local"3 } } ] } ] '$ oc wait --timeout=90m --for=condition=Progressing=false controlplanemachineset.machine.openshift.io -n openshift-machine-api cluster$ oc wait --timeout=90m --for=jsonpath='{.status.updatedReplicas}'=3 controlplanemachineset.machine.openshift.io -n openshift-machine-api cluster$ oc wait --timeout=90m --for=jsonpath='{.status.replicas}'=3 controlplanemachineset.machine.openshift.io -n openshift-machine-api cluster$ oc wait clusteroperators --timeout=30m --all --for=condition=Progressing=false
$ cp_machines=$(oc get machines -n openshift-machine-api --selector='machine.openshift.io/cluster-api-machine-role=master' --no-headers -o custom-columns=NAME:.metadata.name)1 if [[ $(echo "${cp_machines}" | wc -l) -ne 3 ]]; then exit 1 fi2 for machine in ${cp_machines}; do if ! oc get machine -n openshift-machine-api "${machine}" -o jsonpath='{.spec.providerSpec.value.additionalBlockDevices}' | grep -q 'etcd'; then exit 1 fi3 done- 주의
apiVersion: machineconfiguration.openshift.io/v1 kind: MachineConfig metadata: labels: machineconfiguration.openshift.io/role: master name: 98-var-lib-etcd spec: config: ignition: version: 3.4.0 systemd: units: - contents: | [Unit] Description=Mount local-etcd to /var/lib/etcd [Mount] What=/dev/disk/by-label/local-etcd1 Where=/var/lib/etcd Type=xfs Options=defaults,prjquota [Install] WantedBy=local-fs.target enabled: true name: var-lib-etcd.mount - contents: | [Unit] Description=Create local-etcd filesystem DefaultDependencies=no After=local-fs-pre.target ConditionPathIsSymbolicLink=!/dev/disk/by-label/local-etcd2 [Service] Type=oneshot RemainAfterExit=yes ExecStart=/bin/bash -c "[ -L /dev/disk/by-label/ephemeral0 ] || ( >&2 echo Ephemeral disk does not exist; /usr/bin/false )" ExecStart=/usr/sbin/mkfs.xfs -f -L local-etcd /dev/disk/by-label/ephemeral03 [Install] RequiredBy=dev-disk-by\x2dlabel-local\x2detcd.device enabled: true name: create-local-etcd.service - contents: | [Unit] Description=Migrate existing data to local etcd After=var-lib-etcd.mount Before=crio.service4 Requisite=var-lib-etcd.mount ConditionPathExists=!/var/lib/etcd/member ConditionPathIsDirectory=/sysroot/ostree/deploy/rhcos/var/lib/etcd/member5 [Service] Type=oneshot RemainAfterExit=yes ExecStart=/bin/bash -c "if [ -d /var/lib/etcd/member.migrate ]; then rm -rf /var/lib/etcd/member.migrate; fi"6 ExecStart=/usr/bin/cp -aZ /sysroot/ostree/deploy/rhcos/var/lib/etcd/member/ /var/lib/etcd/member.migrate ExecStart=/usr/bin/mv /var/lib/etcd/member.migrate /var/lib/etcd/member7 [Install] RequiredBy=var-lib-etcd.mount enabled: true name: migrate-to-local-etcd.service - contents: | [Unit] Description=Relabel /var/lib/etcd After=migrate-to-local-etcd.service Before=crio.service [Service] Type=oneshot RemainAfterExit=yes ExecCondition=/bin/bash -c "[ -n \"$(restorecon -nv /var/lib/etcd)\" ]"8 ExecStart=/usr/sbin/restorecon -R /var/lib/etcd [Install] RequiredBy=var-lib-etcd.mount enabled: true name: relabel-var-lib-etcd.service $ oc create -f 98-var-lib-etcd.yaml참고$ oc wait --timeout=45m --for=condition=Updating=false machineconfigpool/master$ oc wait node --selector='node-role.kubernetes.io/master' --for condition=Ready --timeout=30s$ oc wait clusteroperators --timeout=30m --all --for=condition=Progressing=false
9장.
9.1.
10장.
10.1.
$ sudo subscription-manager register # If not done already$ sudo subscription-manager attach --pool=$YOUR_POOLID # If not done already$ sudo subscription-manager repos --disable=* # If not done already$ sudo subscription-manager repos \ --enable=rhel-8-for-x86_64-baseos-rpms \ --enable=openstack-16-tools-for-rhel-8-x86_64-rpms \ --enable=ansible-2.9-for-rhel-8-x86_64-rpms \ --enable=rhel-8-for-x86_64-appstream-rpms
$ sudo yum install python3-openstackclient ansible python3-openstacksdk$ sudo alternatives --set python /usr/bin/python3
10.2.
$ ansible-playbook -i inventory.yaml \ down-bootstrap.yaml \ down-control-plane.yaml \ down-compute-nodes.yaml \ down-load-balancers.yaml \ down-network.yaml \ down-security-groups.yaml
11장.
11.1.
11.1.1.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
11.1.2.
|
|
참고
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
참고
|
11.1.3.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
중요
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
중요
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
중요
참고
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
참고
|
|
- 참고중요
11.1.4.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
중요
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
참고
|
|
|
|
|
|
|
|
|
|
11.1.5.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
11.1.6.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
11.1.7.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
중요
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
중요
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
중요
|
|
|
|
|
|
|
|
|
|
Legal Notice
Copyright © Red Hat
OpenShift documentation is licensed under the Apache License 2.0 (https://www.apache.org/licenses/LICENSE-2.0).
Modified versions must remove all Red Hat trademarks.
Portions adapted from https://github.com/kubernetes-incubator/service-catalog/ with modifications by Red Hat.
Red Hat, Red Hat Enterprise Linux, the Red Hat logo, the Shadowman logo, JBoss, OpenShift, Fedora, the Infinity logo, and RHCE are trademarks of Red Hat, Inc., registered in the United States and other countries.
Linux® is the registered trademark of Linus Torvalds in the United States and other countries.
Java® is a registered trademark of Oracle and/or its affiliates.
XFS® is a trademark of Silicon Graphics International Corp. or its subsidiaries in the United States and/or other countries.
MySQL® is a registered trademark of MySQL AB in the United States, the European Union and other countries.
Node.js® is an official trademark of the OpenJS Foundation.
The OpenStack® Word Mark and OpenStack logo are either registered trademarks/service marks or trademarks/service marks of the OpenStack Foundation, in the United States and other countries and are used with the OpenStack Foundation’s permission. We are not affiliated with, endorsed or sponsored by the OpenStack Foundation, or the OpenStack community.
All other trademarks are the property of their respective owners.
'%20d='M201.5%20305.5c-13.8%200-24.9-11.1-24.9-24.6%200-13.8%2011.1-24.9%2024.9-24.9%2013.6%200%2024.6%2011.1%2024.6%2024.9%200%2013.6-11.1%2024.6-24.6%2024.6zM504%20256c0%20137-111%20248-248%20248S8%20393%208%20256%20119%208%20256%208s248%20111%20248%20248zm-132.3-41.2c-9.4%200-17.7%203.9-23.8%2010-22.4-15.5-52.6-25.5-86.1-26.6l17.4-78.3%2055.4%2012.5c0%2013.6%2011.1%2024.6%2024.6%2024.6%2013.8%200%2024.9-11.3%2024.9-24.9s-11.1-24.9-24.9-24.9c-9.7%200-18%205.8-22.1%2013.8l-61.2-13.6c-3-.8-6.1%201.4-6.9%204.4l-19.1%2086.4c-33.2%201.4-63.1%2011.3-85.5%2026.8-6.1-6.4-14.7-10.2-24.1-10.2-34.9%200-46.3%2046.9-14.4%2062.8-1.1%205-1.7%2010.2-1.7%2015.5%200%2052.6%2059.2%2095.2%20132%2095.2%2073.1%200%20132.3-42.6%20132.3-95.2%200-5.3-.6-10.8-1.9-15.8%2031.3-16%2019.8-62.5-14.9-62.5zM302.8%20331c-18.2%2018.2-76.1%2017.9-93.6%200-2.2-2.2-6.1-2.2-8.3%200-2.5%202.5-2.5%206.4%200%208.6%2022.8%2022.8%2087.3%2022.8%20110.2%200%202.5-2.2%202.5-6.1%200-8.6-2.2-2.2-6.1-2.2-8.3%200zm7.7-75c-13.6%200-24.6%2011.1-24.6%2024.9%200%2013.6%2011.1%2024.6%2024.6%2024.6%2013.8%200%2024.9-11.1%2024.9-24.6%200-13.8-11-24.9-24.9-24.9z'/%3e%3c/svg%3e){kind=small}
